2591RT Rough Terrain Scissor Lift

Description

2591RT Rough Terrain Scissor Lift

  • Fully proportional drive and lift controls
  • No-maintenance scissor bearings
  • Roll-out deck extensions with incremental locking positions
  • Non-skid steel deck construction
  • Large sheet loading entrance
  • Easy maintenance access without raising platform or swing-out trays
  • Quad-Trax„ 4wd power package
  • Outrigger support for platform stability on heavy duty jobs sites with one-touch auto leveling
  • Powered by liquid-cooled engine
  • Multiple fuel selections(gasoline/liquid propane or diesel)
  • Oscillating rear axle with 12 (30.48 cm) ground clearance

2591RT Rough Terrain Scissor Lift Features:

Work Area

  • Roll-out deck extension with incremental locking positions
  • Large sheet loading entrance accommodates 48€1.22 m) material
  • 110V Power to Platform
  • Combination of wide beams and large pins in self-lubricating bearings for larger load bearing surface in scissor pivot areas

Performance

  • Fully proportional drive and lift controls
  • Oscillating rear axle with 12 (30.48 cm) ground clearance
  • Quad-Trax 4wd Power Package
  • Engine/Power
  • Multiple Fuel Selections (gasoline/liquid propane or diesel)
  • Liquid-Cooled Engine

Serviceability

  • Lubrication-Free Scissor Bearings
  • Easy maintenance access to mechanical and electrical components without raising platform or swinging out trays
  • Logically grouped components and numbered wiring for easy reference

Safety

  • Dedicated compartments protect electrical and hydraulic components
  • Non-Skid Steel Deck Construction
  • Motion Alarm
  • Drive Speed Interlock
  • Multi-AxisTilt Sensor
  • Multiple Disc Brakes, manual brake release
  • Scissor Maintenance Lock
  • Dual Automatic Parking Brake
  • Emergency shut off at platform and lower controls

2591RT Rough Terrain Scissor Lift Specifications:

 DIMENSIONS
 Length  144 in. (3.66 m)
 Height  Working: 31 ft. (9.62 m)
Maximum Drive: 25 ft. (7.62 m)
Stowed (Top Guardrail): 100.5 in. (2.55 m)
Stowed (Rails Folded): 71 in. (1.8 m)
Guardrail: 44.5 in. (1.13 m)
Toeboard: 7 in. (18 cm)
 Width  91 in. (2.31 m)
 Weight  8,000 lbs. (3,629 kg)
 Ground Clearance  12 in. (30.48 cm)
 Wheelbase  102.5 in. (2.6 m)
 Turning Radius  Inside: 76 in. (1.93 m)
Outside: 195 in. (4.95 m)
 ENGINE & DRIVETRAIN
 Engine Make  Kubota
 Engine Model  DF752
 Engine Type  Dual Fuel
 Fuel Type  Gas & LP
 Fuel Tank Capacity  15 gal. (57 l)
 Drive System  Planetary drive, 2-speed wheel motors
 HYDRAULICS
 Hydraulic System  Variable displacement
 Hydraulic Tank Capacity  23 gal. (87 l)
 PERFORMANCE
 Tires  12 – 16.5 NHS outrigger
 Travel Speed  Stowed: 3.8 mph (6.1 km/h)
Raised: 0.8 mph (1.3 km/h)
 Gradeability  45%
 Capacity  Lift: 2,000 lbs. (907 kg)
Roll-Out Deck: 500 lbs. (227 kg)
 Platform Height  25 ft. (7.62 m)
57 in. (1.45 m) entry height
 Platform Size  Extended Length: 180 in. (4.57 m)
Retracted Length: 132 in. (3.35 m)
Roll-Out Deck: 48 in. (1.22 m)
 Raise/Lower Time  25/30 sec.
