Description

Economical Mechanical Drum Transporter



Economical Mechanical Drum Transporter Features:

• Simple Design

• Completely Mechanical Operation

Unique portable unit designed to lift and transport plastic, steel, and fiber drums with a top lip. Steel jaw securely grips the top lip of the drum. Available with either a manual mechanical ratchet or a foot pump hydraulic lift mechanism. Straddle legs rotate for access to drums on pallets. Unit rolls on (4) 8″ x 2″ phenolic casters. The push handle folds down for easy access to ratchet and foot pump. All welded steel construction.  Powder coated with a safety yellow finish. Optional scale weighs drums to an accuracy of +/-0.5 lbs. Optional scale includes (6) D cell batteries and an AC adaptor.





Economical Mechanical Drum Transporter
Model	PDF’s	Description	Jaw Service Range	Capacity (lbs)	Wt. (lbs)
DCR-880-M		Hand Ratchet	31″to47″	880	275
DCR-880-H		Foot Pump	31″to49″	1,500	293
DCR-880-H-HP		Foot Pump	31″to77-1/2″	880	345
DCR-880-H-DC		(1) 12V DC Powered	31″to49″	1,500	446
DCR-880-H-HP-DC		(1) 12V DC Powered	31″to76″	880	446
DCR-SCALE		Optional Weight Scale		1,500	70







Please contact Industrial Manlifts for specifications and RFQ’s.
