Bombardier(Canadair) Multi-Link Towbar TY-TB125
Bombardier(Canadair) Multi-Link Towbar TY-TB125The Bombardier(Canadair) Multi-Link tow bar has the capacity to handle aircraft up to a gross weight of 125,000 lbs. They are available in 10 ft. and 15 ft. lengths. The inside diameter of the tube that receive the heads is 3 1/4" a reducer insert P.N. TY-RED1 is available to receive heads with 3" dia. This bar is compatible with TronAir, Aero Specialties and other universal tow bars.
Bombardier(Canadair) Multi-Link Towbar TY-TB125 Specifications:
- MATERIAL: ALUM. 4" TUBE
- TOW EYE: 2 1/2" I.D. STANDARD 3" I.D. OPTIONAL
- COLOR: YELLOW POWDER COAT
- TY-TB125 (10 ft.) = 87 lbs.
- TY-TB125-15 (15 ft.) = 109 lbs.
- TY-TB125-5X EXTENSION
- TY-RED1 (REDUCER 3 1/4" TO 3") = 4 lbs.
