M1230E Electric Mast Lift

M1230E Electric Scissor Lift Features: Proportional controls Descent and tilt alarms High amp hour rating gives long usage between charges Emergency lowering at chassis controls Non-marking, solid rubber tires.

M1230E Electric Mast Lift

M1230E Electric Mast Lift Features:

  • Proportional controls
  • Descent and tilt alarms
  • High amp hour rating gives long usage between charges
  • Emergency lowering at chassis controls
  • Non-marking, solid rubber tyres
  • Power line to platform
  • Forklift pockets
  • Saloon door-style platform entry
  • Horn
  • Tie down points
  • 2 persons + equipment capacity indoors
  • 1 person + equipment capacity outdoors
  • Selectable motion
  • ANSI Compliant

OPTIONS:

  • Special paint colors
  • 20 in roll-out extension deck
  • Environmental green oil
  • CSA compliant

M1230E Electric Scissor Lift Specifications

M1230E Electric Mast Lift Specifications:

DIMENSIONS: M1230E
Max. working height: 17 ft 11 in
Max. platform height (A): 11 ft 11 in
Platform size (inside): 29 in x 38 in
Overall width (B): 30 in
Overall length (D): 53 in
Stowed height (C): 64 in
Ground clearance: 3 in
PERFORMANCE:
Platform capacity (SWL): 500 lbs
Max. drive height: 11ft 11in
Max. drive speed (stowed): 2 mph
Max. drive speed (elevated): 0.4 mph
Raise/lower time: 18/25 sec
Gradeability: 25%
Max. operating slope:
(side to side)
1.5°
Max. operating slope:
(front to back)
Inside turning radius: 14.4 in
Outside turning radius: 58.5 in
Tires: 12 in dia. solid rubber, non-marking
Parking brake: 2 wheel, spring-applied, hydraulically-released with manual overdrive
Drive system: dual front hydraulic motors
Controls: proportional
POWER:
Power source: 24V 4hp DC electric motor 4-220 Ah batteries
Battery charger: 90V - 240V - 18 amp automatic
WEIGHT:
Gross weight: 1,720 lbs

Industrial Manlifts is YOUR total aerial access solution provider. We can customize any aerial access solution for any project. Operators standing by, (888) 730-8377.
