Hydraulic Drum Crusher/Compactor

Hydraulic Drum Crusher/Compactor is offered in the listed configurations HDC-905-IDC/460V, HDC-905-HC/460V, HDC-905-IDC/230V, HDC-905-HC/230V, HDC-905-IDC/208V, HDC-905-HC/208V. Compare each row separately; dimensions and capacities belong to the model identified in that row.

The model HDC-900-IDCcrushes 55-gallon steel drums to approximately 6” high and resets automatically to crush another drum in only 25 seconds.

This unit is designed for a duty cycle that will allow for crushing or compacting up to 250 drums per week in a typical non-hazardous, indoor room-temperature environment when operated on a three-phase power supply.

Standard duty equals 10 crushes per hour for 3 hours max or 30 crushes per day.

The included drum compacting feature allows you to compact contents inside the drum by simply removing the drum crushing platen.

Crushing feature will work with any drum size up to 55-gallons.

Compacting feature will only work with 55-gallon drums.

This convenient design gives you two pieces of equipment in one.

Safety features include a pressure relief valve, which prevents overload, and a door interlock system that will prevent the motor from running unless the door is closed.

6.5 hp motor is 460V, 3-phase, 60 hz.

Built-in fork pockets aid in transporting.

Aluminum Drip Pan, model HDC-DPN, is available for catching any excess liquid that may be expelled during the crushing operation.

gallons and measures 30"W x 20"D x 3"H.

For Hydraulic Drum Crusher/Compactor, the catalog lists Listed models: HDC-905-IDC/460V, HDC-905-HC/460V, HDC-905-IDC/230V, HDC-905-HC/230V and additional configurations; HDC-905-IDC/460V Description: Crusher/Compactor (460V, 3 Phase); HDC-905-IDC/460V Wt. (lbs): 1570. Match these details to the configuration being quoted; options and model variants may differ.
